2 WAY REMOTE MOUNT VALVE (TYPE 2)
2 WAY REMOTE MOUNT VALVE
(TYPE 2)
The 2-Way Remote Mount Valve (Type 2) is a specialized isolation valve engineered for remote pressure measurement systems, where direct mounting of instruments is not suitable. Unlike Type 1, Type 2 offers enhanced accessibility and features such as panel or bracket mounting, making it ideal for instrument enclosures, control rooms, or remote hook-up installations. This valve is widely used in oil & gas fields, petrochemical facilities, refineries, offshore rigs, and power plants for isolating pressure instruments during calibration, maintenance, or emergency operations.
- 2-Port Configuration: One process inlet, One outlet to instrument tubing or fittings
- End Connections: Female NPT (or BSP) on both ports – typically 1/4″ or 1/2″
- Mounting Options: Remote wall or panel mounting using brackets or clips
- Designed to integrate with remote instrument panels or racks
- Body Design: Compact barstock or forged body, Rugged construction suitable for corrosive and high-pressure environments
- Stem Tip Options: Non-rotating, soft-seat, or metal-to-metal sealing
- Pressure Rating: Standard up to 6,000 psi (414 bar); higher ratings available
- Temperature Range: PTFE packing: Up to 232°C, Graphite packing: Up to 425°C
- Material Options: SS316, SS304, Monel, Hastelloy, Duplex, Carbon Steel, etc.
- Remote mounting reduces exposure of instruments to vibration, heat, or hazardous process conditions.
- Safe and quick isolation of instruments during calibration or repair.
- Clean layout for instrument panels and control room interfaces.
- Longer instrument life due to minimized stress from harsh process environments.
- Leak-proof operation even under high-pressure conditions.
- Customizable configurations for different process standards and installations.
| Valve Size | Inlet Port | Outlet Port | Orifice Size | Pressure Rating | Body Material |
|---|---|---|---|---|---|
| 1/4″ | 1/4″ NPT Female | 1/4″ NPT Female | 2.5 – 3.0 mm | Up to 6,000 psi | SS316 / CS / Monel |
| 1/2″ | 1/2″ NPT Female | 1/2″ NPT Female | 4.0 – 5.0 mm | Up to 6,000 psi | SS316 / CS / Monel |
